  • DMON-12S

Decimator DMON-12S 12 Channel Multiviewer with SDI and HDMI Outputs for 3G/HD/SD and Custom Layouts

BP #: DD-DMON-12S  |  MFR #: DMON-12S

Availability: Call for availability

$1,995.00

Quick Overview

The DMON-12S is a low cost miniature (3G/HD/SD)-SDI 12 to 1 Multiviewer or 12 to 1 input multiplexer

Details

The DMON-12S is a truly portable converter, that incorporates our new easy to use LCD and button control system. This gives you easy access to most of the amazing features without using complicated LED/button control, dip switches or having to carry around a computer to change a simple setting.

•  Low cost miniature (3G/HD/SD)-SDI 1 to 12 channel Multi-Viewer or
    12 to 1 input multiplexer
•  Custom Layouts with various standard layouts
•  Fast switching between inputs using Full-Screen scaling
•  Selectable output format in both Full-Screen and Multi-Viewer mode
•  Low latency buffering for each input allowing non-synchronous
    inputs
•  Linked (3G/HD/SD)-SDI and HDMI outputs
•  12 x (3G/HD/SD)-SDI inputs with auto detection
    (26 Formats supported in total)
•  Each quadrant is independent of the others, allowing any
    3G/HD/SD format of any frame rate to be displayed
    simultaneously
•  Variable aspect ratios per quadrant
•  Pass-Through mode allowing any of the 12 inputs to be
    selected for output
•  In Pass-Through mode the selected input is passed through
    to both the (3G/HD/SD)-SDI and HDMI outputs
•  This unit also includes:
    -  32 GPI on 37-pin for Tallies and Remote Switching
    -  RS422/485 on 37-pin DSUB for Tallies
    -  USB port for control and firmware updates
    -  Heavy duty metal box
    -  Metal Thread Locking DC Power Socket
    -  Power Supply, HDMI Cable and USB Cable
